Cofi TRE 820 Ignition Transformer
Cofi TRE 820 Ignition Transformer is backordered and will ship as soon as it is back in stock.
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Cofi TRE 820 Ignition Transformer
Highlight title
Text to highlight a key feature of your product
Description
Description
TRE 820 - Dual Voltage Single Outlet Transformer
Versatile 2x4kV/30mA Single Outlet Intermittent Inductive Transformer
The TRE 820 offers unique dual voltage capability with 2x4kV output at 30mA through a single outlet. This innovative design provides flexible voltage options for applications requiring variable high-voltage configurations with intermittent duty reliability.
Key Technical Specifications:
- Output Voltage: 2x4kV (dual voltage configuration)
- Current Rating: 30mA
- Operation Type: Intermittent duty
- Outlets: 1 high-voltage outlet
- Supply Voltage: 230VAC, 50Hz
- Supply Cable: 3 x 0.75 mm² conductors
- Overall Length: 440mm (380mm useable length)
- Weight: Approximately 2.8kg (heavy-duty construction)
- Insulation Class: Class H windings
- Encapsulation: Epoxy resin protection
- Compliance: EC Approval certified
- Mounting: Flush self-tapping screw outlet (13mm deep)
Perfect for applications requiring voltage flexibility, testing environments with multiple voltage requirements, and systems needing configurable high-voltage output.
